Jet BA9-1008396 H-frame Shop Press 50 Ton

Product Description

The JET BA9-1008396 is a 50-ton air and hand operated H-frame shop press built for fabrication shops, machine shops, and industrial service environments. The main frame is fully welded steel, providing the rigidity required to apply full pressing force repeatedly without frame deflection. A large-diameter cylinder with a 7.8-inch stroke delivers consistent hydraulic force, while the integrated manual hand pump allows controlled, low-speed pressing for precision or delicate applications. A foot pedal provides hands-free cycle control during normal press operations. This unit ships at 770 pounds and is intended for permanent or semi-permanent floor installation by qualified shop personnel.

This H-frame press is suited for pressing bearings, bushings, shafts, and pins in fabrication and production machine shop environments. The 28.5-inch working width accommodates a wide range of workpiece sizes. The winch and pulley system allows the working table to be repositioned without manual lifting, reducing downtime when adjusting for different workpiece heights. A set of V-blocks is included as standard equipment, making the unit ready for round-stock work immediately upon installation.

Key Features

• 50-ton pressing capacity with fully welded steel H-frame for maximum rigidity
• Air and hand dual-operation: pneumatic cylinder for production use, manual hand pump for precision control
• 28.5-inch working width accommodates large or oddly shaped workpieces
• Large cylinder with 7.8-inch stroke delivers extended reach for deep pressing applications
• Foot pedal for hands-free cycle activation during pneumatic operation
• Winch and pulley table positioning system reduces manual handling and repositioning time
• V-blocks included as standard equipment for round-stock pressing and support

Compatibility

Designed as a standalone floor-mounted H-frame shop press for fabrication and machine shop use. No specific equipment compatibility data was provided with this listing.

Installation Notes

Installation should be performed by qualified personnel familiar with heavy industrial equipment. The unit must be anchored to a level concrete floor capable of supporting the machine weight and applied pressing loads. Pneumatic supply lines must be connected in accordance with the equipment specifications and local compressed-air system codes before operation. Disconnect all air supply and relieve hydraulic pressure before performing any maintenance or adjustments.

Technical Specifications

• Press Capacity: 50 tons
• Working Width: 28.5 inches
• Cylinder Stroke: 7.8 inches
• Operation Type: Air and hand operated
• Frame Construction: Fully welded steel
• Weight: 770 pounds

Standard Information

• Brand: JET
• Manufacturer Part Number: BA9-1008396
