Jet BA1-162 Variable Speed Horizontal Vertical Bandsaw

Product Description

The JET BA1-162 is a variable speed horizontal and vertical bandsaw designed for metal cutting in shop and industrial environments. Running on 115 volts, it is powered by a 1/2 HP motor and delivers blade speeds from 80 to 230 feet per minute, giving operators the control needed to cut a range of ferrous and non-ferrous materials. The saw accommodates a 1/2 inch x 0.025 inch x 65 inch blade and features 7-3/8 inch blade wheels. Licensed electricians, millwrights, and fabrication shop techs typically install and commission this unit. It weighs 150 pounds and is built for stationary shop use.

The BA1-162 is suited for metal fabrication shops, maintenance facilities, and production environments where both horizontal and vertical cutting orientations are needed. Its variable speed control supports work on different material types and thicknesses. The vise swivels up to 45 degrees, enabling angled cuts without repositioning the workpiece. The 5 inch throat depth accommodates typical structural stock found in light to medium fabrication work. Overall dimensions are 24 inches long by 17 inches wide by 49 inches tall, making it a practical fit for smaller shop footprints.

Key Features

• Dual horizontal and vertical cutting orientations for versatile shop use
• Variable blade speed from 80 to 230 feet per minute for material-matched cutting
• Vise swivels up to 45 degrees for angled cuts
• 1/2 HP motor on standard 115 volt single-phase power
• 7-3/8 inch blade wheels support a 1/2 inch x 0.025 inch x 65 inch blade
• 5 inch throat depth suitable for light to medium structural stock

Compatibility

The BA1-162 corresponds to the Baileigh model BHVBS-56V and accepts standard 1/2 inch x 0.025 inch x 65 inch bandsaw blades compatible with that platform.

Installation Notes

Installation should be performed by a qualified technician familiar with stationary power tool setup and applicable electrical codes. Disconnect and lock out all power before servicing the blade, guides, or drive components. The unit requires a grounded 115 volt circuit rated for the motor load. Secure the saw to a stable, level surface before operation to prevent movement during cutting cycles.

Technical Specifications

• Motor: 1/2 HP
• Voltage: 115 volts
• Blade Speed: 80-230 feet per minute (variable)
• Blade Size: 1/2 inch x 0.025 inch x 65 inches
• Blade Wheel Diameter: 7-3/8 inches
• Throat Depth: 5 inches
• Vise Swivel Range: 45 degrees
• Overall Dimensions: 24 inches L x 17 inches W x 49 inches H
• Weight: 150 pounds

Standard Information

• Brand: JET
• Manufacturer Part Number: BA1-162
