Jet 511000 Chain Hoist 5 Ton 10 in Lift 115 230V

Product Description

The JET 511000 is a single-phase electric chain hoist rated for 5 tons of lifting capacity with a 10-inch lift range. It operates on 115 or 230 volts and comes prewired for 230V out of the box, reducing field wiring time on the initial installation. Weighing 236 pounds, this is a heavy-duty unit built for industrial and commercial lifting applications. It is designed for overhead lifting tasks where a reliable, single-phase power supply is available and a compact lift distance is required.

This chain hoist is suited for manufacturing facilities, maintenance shops, loading docks, and fabrication environments where repetitive or heavy lifting is part of daily operations. The single-phase configuration makes it compatible with standard commercial power feeds without requiring three-phase service. The 10-inch lift is appropriate for applications where short, controlled vertical movement is the primary requirement, such as positioning components, loading machinery, or supporting assembly line workflows. Licensed electricians and rigging professionals typically handle installation and commissioning.

Key Features

• 5-ton rated lifting capacity for heavy industrial loads
• Single-phase motor compatible with 115V or 230V power supply
• Prewired for 230V to simplify installation and reduce field wiring steps
• 10-inch lift range for controlled short-distance vertical movement
• Robust construction suited for demanding commercial and industrial environments

Compatibility

Designed as a direct-install single-phase electric chain hoist for overhead lifting applications requiring 5-ton capacity with a 10-inch lift on 115 or 230-volt single-phase power systems.

Installation Notes

Installation should be performed by a qualified electrician and a certified rigger familiar with overhead lifting equipment and applicable OSHA regulations. Disconnect and lock out all power sources before wiring or servicing the unit. Verify that the supporting structure, beam, or trolley is rated to handle the full hoist load plus dynamic forces before mounting. Do not exceed the rated 5-ton capacity under any operating condition.

Technical Specifications

• Lifting Capacity: 5 Ton
• Phase: 1 Phase
• Voltage: 115 or 230 volts
• Prewired Voltage: 230 volts
• Lift: 10 inches
• Weight: 236 pounds
• UPC: 662755906244

Standard Information

• Brand: JET
• Manufacturer Part Number: 511000
