Jet 414308 Bi-metal Bandsaw Blade 1 Inch X 130.5 Inches

Product Description

The JET 414308 is a bi-metal replacement blade designed for the JET 10-inch by 18-inch horizontal bandsaw. It runs 130.5 inches in length, 1 inch wide, and 0.035 inches thick, with a 4/6 variable-tooth pitch that handles a range of metal stock sizes efficiently. Bi-metal construction bonds a high-speed steel tooth edge to a flexible alloy steel backer, delivering longer blade life and resistance to tooth strippage compared to carbon-steel blades. Metalworking shops and maintenance technicians rely on this blade for production metal cutting applications.

This blade is suited for horizontal band sawing of ferrous and non-ferrous metals in fabrication shops, maintenance facilities, and job sites. The 4/6 variable-tooth pitch transitions between 4 and 6 teeth per inch, making it effective on solid bar stock, structural shapes, and tubing. It is a direct replacement blade intended for the corresponding JET horizontal bandsaw model and is sold as a single blade.

Key Features

• Bi-metal construction with high-speed steel teeth bonded to a flexible alloy steel backer for extended blade life
• 4/6 variable-tooth pitch for efficient cutting across a range of cross-sections and material types
• 130.5-inch loop length matches the JET 10-inch by 18-inch horizontal bandsaw wheel spacing
• 1-inch blade width provides rigidity and straight tracking on horizontal bandsaw guides
• 0.035-inch blade thickness compatible with the guide and tension specifications of the corresponding saw

Compatibility

Designed as a direct OEM-style replacement blade for the JET 10-inch by 18-inch horizontal bandsaw as specified by manufacturer part number 414308.

Installation Notes

Blade replacement should be performed by a qualified technician with the saw powered off and unplugged. Always release blade tension before removing the worn blade and inspect guide bearings and guide inserts for wear before installing the new blade. Wear cut-resistant gloves when handling bandsaw blades, as the tooth edge presents a laceration hazard. Verify blade tracking and tension per the saw manufacturer's guidelines before returning the machine to service.

Technical Specifications

• Blade Length: 130.5 inches
• Blade Width: 1 inch
• Blade Thickness: 0.035 inches
• Tooth Pitch: 4/6 variable TPI
• Blade Material: Bi-Metal (HSS teeth, alloy steel backer)
• Compatible Saw Size: 10 inches x 18 inches horizontal bandsaw
• Weight: 1 pound
• Sold As: Each

Standard Information

• Brand: JET
• Manufacturer Part Number: 414308
