Jet 208130 Lever Hoist 5 Ton 30 Ft Overload Protection

Product Description

The JET 208130 is a heavy-duty lever hoist rated for 5 tons of lifting capacity with 30 feet of lift travel and built-in overload protection. Lever hoists like this unit are used to lift, pull, and position heavy loads in tight spaces where overhead cranes or powered equipment cannot reach. The overload protection mechanism prevents the hoist from operating beyond its rated capacity, reducing the risk of equipment damage and load drop incidents. At 136.4 pounds, this is a substantial unit intended for demanding industrial and construction applications where reliable manual lifting is required.

The JET 208130 is suited for rigging, maintenance, and material handling work across industrial facilities, shipyards, construction sites, and mechanical contractor applications. It is used by riggers, millwrights, ironworkers, and mechanical contractors who need a portable manual hoist capable of managing multi-ton loads. The 30-foot lift range accommodates a wide variety of vertical and horizontal pulling scenarios, making it a practical tool for both overhead lifting and load tensioning tasks.

Key Features

• 5-ton rated lifting capacity for heavy industrial and construction loads
• 30-foot lift travel provides extended vertical range
• Built-in overload protection prevents operation beyond rated capacity
• Manual lever operation allows precise load positioning without power source
• Portable design suited for field and shop use

Compatibility

Designed as an OEM-style manual lever hoist for general industrial lifting and rigging applications requiring 5-ton capacity and 30-foot lift range.

Installation Notes

Installation and operation should be performed by qualified riggers or trades personnel familiar with ASME B30.21 standards for lever hoists. Always inspect the hook, chain, and load brake before each use and confirm the supporting structure is rated to handle the full hoist load. Never exceed the rated 5-ton capacity, and ensure the overload protection device is functional before each lift. Remove the load and store the hoist properly after each job to preserve brake and chain integrity.

Technical Specifications

• Lifting Capacity: 5 tons
• Lift Travel: 30 feet
• Overload Protection: Yes
• Weight: 136.4 pounds
• UPC: 731325172317

Standard Information

• Brand: JET
• Manufacturer Part Number: 208130
