Jet 141800 jtx series manual pallet jack 8000 lb. capacity, 27 inchesw x 48 inchesl forks

Product Description

The JET 141800 JTX Series Pallet Truck JTX-2748A has a heavy duty capacity of 8,000 pounds. It features a low profile of 3-1/4 inches, a width of 27 inches, and a length of 48 inches. The 210 degree turning radius increases maneuverability, and the easy-to-use fingertip controls permit single handed operation. This pallet truck is built to handle heavy lifting.

• Heavy duty capacity of 8,000 pounds
• Low profile of 3-1/4 inches
• 210 degree turning radius increases maneuverability
• Easy-to-use fingertip controls permit single handed operation
• Fork dimensions of 27" W x 48" L

Product Highlights

The JET JTX Series Pallet Truck is designed for heavy lifting with a focus on maneuverability and ease of use.

Product Information

Standard Information

• Brand: JET
• Manufacturer Part Number: 141800

Technical Specifications

• Type: General Purpose
• Brand: JET
• Color: Gray
• Style: Standard Forks
• Series: JTX
• Material: Steel
• Operation: Manual
• Wheel Type: 2 Load, 2 Steer
• Width: 27 in
• Height: 48 in
• Length: 63 in
• Entry Rollers: Yes
• Fork Width: 6-1/4 in
• Fork Length: 48 in
• Assembly Required: No
• Steer Arc Degrees: 200 °
• Raised Height: 7-1/2 in
• Load Wheel Material: Polyurethane
• Lowered Height: 2-15/16 in
• Steer Wheel Material: Polyurethane
• Weight Capacity: 8000 lbs
• Distance Across Forks: 27 in
• Distance Between Forks: 14-1/2 in
• Manufacturers Part Number: 141800
• Electric Brake: No
• Variable speed: No
• Wheel Material: Polyurethane
• Load Wheel Outter Diameter: 2 7/8"
• Load Wheel Width: 3 11/16"
• Maximum Height: 7 1/2"
• Overall Length: 63"
• Overall Width: 27"
• Overall Height: 48"
• Overall Fork Length: 48"
• Overall Fork Width: 27"
• Steer Wheel Size: 6 1/4" x 2"
• Turning Radius: 200 Deg
• Capacity (Lbs.): 8000
• Fork Width (In.): 6-1/4
• Load Wheel Size (OD x W) (In.): 2-7/8 x 3-11/16
• Lowered Height (In.): 2.95
• Maximum Height (In.): 7-1/2
• Overall Dimensions (L x W x H) (In.): 63 x 27 x 48
• Overall Fork Dimensions (L x W) (In.): 48 x 27
• Steer Wheel Size (In.): 6-1/4 x 2
• Turning Radius (Deg): 200
• Handle Style: Ergonomic
