Jet 101100 Lever Hoist 1.5 Ton 10 Foot Lift

Product Description

The JET 101100 is a 1.5-ton lever hoist with a 10-foot lift range and built-in overload protection. It is a manually operated chain hoist designed for lifting, pulling, and positioning heavy loads in industrial, construction, and maintenance environments. The overload protection mechanism prevents the hoist from operating beyond its rated capacity, reducing the risk of equipment damage and operator injury. Weighing 36 pounds, it is a robust unit intended for professional use by riggers, millwrights, ironworkers, and general maintenance trades requiring reliable mechanical lifting capability.

This lever hoist is suited for applications where a powered lift is unavailable or impractical. Typical uses include equipment rigging in confined spaces, load tensioning, and vertical or horizontal load movement. The 10-foot lift range accommodates most standard overhead rigging setups. It is appropriate for both light industrial and heavy-duty maintenance tasks in commercial and industrial settings.

Key Features

• 1.5-ton (3,000 lb) rated load capacity
• 10-foot lift range for standard overhead rigging applications
• Built-in overload protection prevents operation beyond rated capacity
• Manual lever operation requires no power source
• Compact and portable at 36 pounds for field use

Compatibility

Designed as an OEM-style replacement or direct-use lever hoist for standard rigging and lifting applications requiring a 1.5-ton rated manual chain hoist with a 10-foot lift.

Installation Notes

Installation and rigging of lever hoists should be performed by qualified riggers or tradespeople familiar with ASME B30.21 standards for lever hoists. Before use, inspect the mounting point, hook, and chain for wear or damage. Never exceed the rated load capacity. Ensure the overhead anchor point is rated to handle the full dynamic load before lifting operations begin.

Technical Specifications

• Load Capacity: 1.5 tons
• Lift Height: 10 feet
• Overload Protection: Yes
• Weight: 36 pounds
• UPC: 662755995361

Standard Information

• Brand: JET
• Manufacturer Part Number: 101100
