JCM Industries 402-0905X14IP 8 x 2 in. IP Ductile Iron Electro-Galvanized Double Strap Saddle

Product Description

The JCM Industries 402-0905X14IP is a double strap saddle made from ductile iron. It measures eight by two inches and features an electro-galvanized finish. This saddle is designed for effective and reliable connections in various underground water service applications.

• Strong ductile iron body ensures durability.
• Pressure-activated gasket for secure connections.
• Wide body design for added stability.

Product Highlights

This saddle provides a dependable solution for tapping pipe connections. The heavy-duty construction allows for long-term service, while the corrosion-resistant features enhance its longevity.

Product Information

Standard Information

• Brand: JCM Industries
• Item Name: Service Saddle

Technical Specifications

• Connection Size: 8 x 2 inches
• Connection Type: IPS x FNPT
• Material: Ductile Iron
• Finish: Standard Shop Coated Primer
• Pressure Rating: 250 psi
• Outside Diameter: 8.63 - 9.05 inches
• Type: Double Strap
• Material Specifications: ASTM A536
• Standards/Certifications: ANSI/AWWA C800, ANSI/NSF 61 certified
