JCM Industries 402-0350X14IP 3 x 2 in. IP Double Strap Saddle

Product Description

The JCM Industries 402-0350X14IP is a 3 x 2 inch IP double strap saddle designed for tapping pipe for branch connections. This product is made from ductile iron, ensuring durability and long-lasting use. The double strap design offers added stability and strength, making it suitable for various applications in plumbing and water service.

• Strong ductile iron construction for durability
• Pressure-activated gasket for reliable sealing
• Corrosion-resistant shop coat primer finish

Product Highlights

The JCM 402 saddle is characterized by its robust design and effective functionality. It features a wrap-around design that supports the pipe while providing excellent stability, which is critical for maintaining safe connections.

Product Information

Standard Information

• Brand: JCM Industries
• Part Number: 402-0350X14IP

Technical Specifications

• Connection Size: 3 x 2 in
• Connection Type: IPS x FNPT
• Material: Ductile Iron
• Finish: Standard Shop Coated Primer
• Pressure Rating: 250 psi
• Outside Diameter: 3-1/4 - 3-1/2 in
• Standards/Certifications: ANSI/AWWA C800, ANSI/NSF 61 certified
• Type: Double Strap
