Jason Industrial 4L920 FHP V-belt (92 in Outside Length) A90

Product Description

Jason Industrial 4L920 is a 4L section FHP V-belt designed for fractional horsepower industrial drives. It has a 92 inch outside length, 1/2 inch top width, 5/16 inch depth and 11/32 inch thickness. The belt uses a chloroprene rubber body with a polyester tension cord and a fabric cover for wear and heat resistance. Typical applications include light-duty single belt drives such as fans, blowers, and bench tools.

• 4L section fractional horsepower V-belt, 92 in outside length, 1/2 in top width, 5/16 in depth
• Chloroprene rubber body with polyester tension cord and fabric cover for wear and heat resistance
• High cord line design; oil- and heat-resistant and static dissipating for light-duty drives

Product Highlights

4L section FHP V-belt, 92 in outside length, chloroprene construction, polyester cord, static dissipating, suited for light-duty fans, blowers, and bench tools

Product Information

Standard Information

• Brand: JASON INDUSTRIAL
• Manufacturer Part Number: 4L920

Technical Specifications

• Brand: Jason Industrial
• Model / MPN: 4L920
• Alternate MPN: A90
• Section: 4L
• Outside Length: 92 in
• Inside Length: 90 in
• Top Width: 1/2 in
• Depth: 5/16 in
• Thickness: 11/32 in
• Number of Ribs: 1
• Cogged: No
• Material / Construction: Chloroprene rubber body with polyester tension cord; fabric cover resists wear and heat
• Cord Material: Polyester
• Cover Material: Fabric (wear- and heat-resistant)
• Weight: 0.400 lb
• Intended Horsepower: Fractional horsepower (for engines 1 HP or less)
• Construction: High cord line design
• Resistance: Oil- and heat-resistant
• Static Dissipating: Yes
• Typical Uses: Light-duty single belt drives (fans, blowers, bench tools)
• Compliance: Conforms to ARPM standards
• Primary SKU: 1984399
• Other SKUs: 2591672, 222877
• UPC: 00746041001445
