Jackson Safety 23606 Standard Centering Head (360 Degree Dial 2.5 Degree Increments) 23608/23610

Product Description

The Jackson Safety 23606 Standard Centering Head is a precision layout and marking tool for pipe fitters, welders, and fabricators. It features aerospace-grade anodized aluminum construction, rare-earth magnets for secure hands-free positioning, a one-piece Y-shaped body with a 360 degree adjustable dial calibrated in 2.5 degree increments, a built-in bubble vial for alignment, and a hardened EN31 steel centering pin for direct marking. Suitable for pipe diameters 0.5" to 4".

• Aerospace-grade anodized aluminum one-piece Y-shaped body for durability and stability
• 360 degree adjustable dial calibrated in 2.5 degree increments with built-in bubble vial for precise angular alignment
• Rare-earth magnets for hands-free positioning and a hardened EN31 steel centering pin that can be tapped for direct marking

Product Highlights

Precision centering and angle layout tool for 0.5" to 4" pipe diameters; replacement parts 23608 and 23610.

Product Information

Standard Information

• Brand: JACKSON SAFETY
• Manufacturer Part Number: 23606
• Country of Origin: India

Technical Specifications

• Brand: Jackson Safety
• Manufacturer Part Number: 23606
• Product Name: Standard Centering Head
• Material: Aerospace-grade anodized aluminum
• Magnetic: Yes (rare-earth magnets)
• Pipe Diameter Range: 0.5" to 4"
• Dial Adjustment: 360 degree adjustable dial, calibrated in 2.5 degree increments
• Centering Pin Material: Hardened EN31 steel (tappable)
• Body Style: One-piece Y-shaped body
• Bubble Vial: Built-in bubble vial
• Replacement Parts: 23608, 23610
• Country of Origin: India
• Intended Applications: Centerline layout, angle finding, keyway and butt-in marking
