Jackson Safety 14560 Passive Filter Plate Shade 9

Product Description

The JACKSON SAFETY 14560 is a passive filter lens plate designed for use in welding helmets. Rated at shade 9, this filter plate reduces arc radiation and intense visible light during welding operations. Constructed from polycarbonate, it provides impact-resistant optical protection in a lightweight format. The plate is part of a complete lens system that includes cover lenses, passive filter lenses, safety plates, and magnifying plates. Licensed welders and welding technicians install these components as part of routine helmet maintenance to ensure continued eye and face protection compliance.

This filter plate is intended for welding applications where a shade 9 passive lens is appropriate, typically covering lower-amperage MIG, TIG, or flux-core processes. It fits directly into the W10 and W20 Series passive welding helmets from JACKSON SAFETY. Replacement of worn or scratched filter lenses is standard maintenance practice in fabrication shops, construction sites, and maintenance facilities.

Key Features

• Shade 9 passive filter lens for arc radiation and light attenuation
• Polycarbonate construction for impact resistance and lightweight wear
• Compatible with W10 and W20 Series passive welding helmets
• Functions as part of a complete lens stack: cover lenses, filter lenses, safety plates, and magnifying plates
• Sold individually (each)

Compatibility

Designed for use with JACKSON SAFETY W10 and W20 Series passive welding helmets.

Installation Notes

Filter plate replacement is performed by welding technicians or equipment maintenance personnel. Remove the helmet from service before replacing any lens components. Follow the helmet manufacturer's lens-assembly sequence to ensure the filter plate, cover lens, and safety plate are seated correctly before returning the helmet to use. Verify shade rating requirements meet applicable ANSI Z87.1 standards for the welding process being performed.

Technical Specifications

• Lens Type: Passive filter plate
• Shade: 9
• Material: Polycarbonate
• Unit of Measure: Each
• Minimum Order Quantity: 25
• UPC: 626053604264

Standard Information

• Brand: JACKSON SAFETY
• Manufacturer Part Number: 14560
