Ives 09162 Steel Flush Bolt Rod 24 Inches FB457 FB459

Product Description

The IVES 09162 is a steel extension rod designed for use with IVES flush bolt models FB457 and FB459 on metal doors. At 24 inches in overall length with a 0.25-inch square cross-section, this rod transmits the throw force from the flush bolt actuator to the top or bottom latch point. It is a direct replacement or supplemental component for applications where door height or frame configuration requires a longer rod. Commercial door hardware installers and finish carpenters working on paired metal door assemblies will encounter this part regularly.

This rod is intended for metal door applications where IVES FB457 or FB459 flush bolts are specified. Flush bolt rod extensions are commonly used on double-door or inactive leaf configurations in commercial and institutional buildings where positive latching at both the head and sill is required. The 09162 fits within the edge routing of the door and operates without protruding hardware when the door is closed, maintaining a clean door edge profile.

Key Features

• Steel construction provides durability in high-cycle commercial door applications
• 24-inch length suits tall door leaves or extended throw requirements
• 0.25-inch square profile matches the channel routing of FB457 and FB459 flush bolt hardware
• Sold individually, allowing replacement of worn or damaged rods without full hardware replacement
• Compatible with top and bottom flush bolt configurations on metal doors

Compatibility

Designed for use with IVES flush bolt models FB457 and FB459 on metal door assemblies. Verify rod length and cross-section against the specific flush bolt model before ordering.

Installation Notes

Installation is performed by commercial door hardware installers or finish carpenters familiar with flush bolt systems. Ensure the door is secured open and any connected hardware is disengaged before removing or inserting the rod. The rod must seat fully within the edge channel without binding to allow smooth bolt operation. Consult applicable building and accessibility codes when specifying flush bolt hardware for fire-rated or ADA-governed openings.
