Iscar 5622717 Corner Chamfer End Mill 0.5 in 4 Flute

Product Description

The ISCAR 5622717 is a solid carbide corner chamfer end mill designed for precise edge-breaking and chamfering operations on ferrous and non-ferrous workpieces. It features a 0.5-inch diameter with a 1-inch length of cut, a 0.02-inch chamfer width, and four flutes ground with a 38-degree helix angle. The TiAlN coating provides elevated heat resistance and extended tool life at high cutting speeds. This is a single-end, centercutting tool with right-hand flute direction and right-hand cutting action. Machinists and tool-and-die professionals install this end mill in CNC machining centers and manual mills where a controlled corner chamfer geometry is required.

This end mill is suited for milling operations requiring consistent edge preparation, corner breaking, or chamfering on machined components. The centercutting capability allows plunge entry, expanding its application to slotting and ramping moves where needed. With a 0.5-inch shank diameter and 3-inch overall length, it mounts directly in standard ER or end mill holders. It is appropriate for use in job shops, production machining environments, and aerospace or general manufacturing applications where tight chamfer tolerances and surface finish consistency are critical.

Key Features

• 0.02-inch chamfer width for precise, repeatable edge preparation
• TiAlN coating for high-temperature resistance and extended tool life
• 38-degree helix angle promotes smooth cutting action and chip evacuation
• Four flutes provide a balance of chip clearance and surface finish quality
• Centercutting geometry enables plunge, ramp, and slot entry
• Right-hand cut and right-hand flute direction for standard spindle operation

Compatibility

Designed as an OEM-style solid carbide end mill fitting standard 0.5-inch end mill holders and collet chucks used in CNC and manual milling applications.

Installation Notes

Installation should be performed by a qualified machinist or toolroom professional. Ensure the spindle is fully stopped and the machine is in an energy-isolated state before mounting or removing the tool. Seat the shank fully in the holder to the minimum insertion depth recommended by the holder manufacturer, and verify runout with a dial indicator before starting a cut. Follow the tool manufacturer and machine builder guidelines for feeds, speeds, and coolant application appropriate to the workpiece material.
