Iscar 3367511 Indexable Cutoff Blade Double End Rh

Product Description

The ISCAR 3367511 is a double-end, right-hand indexable cutoff blade from the LOGIQFGRIP TGAQ product line. Designed for parting and grooving operations on CNC lathes and turning centers, this blade accepts TAG-style inserts with a 3mm insert width. The blade measures 90.5mm in height, 2.5mm in width, and 90.5mm in overall length, supporting a maximum depth of cut of 60mm and a maximum workpiece diameter of 120mm. Its square blade type and double-end design allow the blade body to be repositioned when one end wears, extending useful service life. Metalworking machinists and toolroom technicians install and index this blade as part of a modular grooving and cutoff tooling system.

This cutoff blade is suited for parting operations on medium to large diameter bar stock and turned components in production and job-shop environments. The right-hand cutting direction is consistent with standard lathe spindle rotation. With a maximum workpiece diameter of 120mm and a 60mm maximum depth of cut, it handles a wide range of shaft and sleeve parting applications on conventional and CNC turning equipment. The LOGIQFGRIP clamping system secures TAG-style inserts rigidly to minimize vibration and deflection during deep parting passes.

Key Features

• Double-end blade body — reposition to use second end when first end reaches end of service life
• Right-hand cutting direction for standard lathe spindle rotation
• Accepts TAG-style inserts with a fixed 3mm insert width
• Maximum depth of cut of 60mm supports parting of large-diameter workpieces up to 120mm
• Square blade type for consistent seating and repeatable tool height
• Part of the LOGIQFGRIP TGAQ modular grooving and cutoff system

Compatibility

Compatible with LOGIQFGRIP TGAQ toolholders and clamping blocks designed for TAG-style inserts at 3mm insert width. Manufacturers catalog number TGAQ D120-3-4Z-JHP.

Installation Notes

Installation and indexing should be performed by a qualified machinist or toolroom technician with the machine in a locked-out, zero-energy state per applicable lockout/tagout procedures. Seat the blade body fully in the toolholder block and verify clamping torque meets the toolholder manufacturer specifications before resuming cutting operations. Inspect the insert pocket and clamping surfaces for chips or debris before seating a new insert. Do not exceed the rated maximum workpiece diameter or depth of cut specified for this blade.
