Iscar 2301914 Tang-grip Indexable Cutoff Blade Tgfs

Product Description

The ISCAR 2301914 is a single-end, neutral-cutting indexable cutoff and grooving blade in the Tang-Grip TGFS series. Designed for parting, grooving, and turning operations on CNC lathes and turning centers, this blade accepts TAG-style inserts secured by a clamp-type holding method. It measures 17.2 mm (0.677 inches) in height and 1.65 mm (0.065 inches) in width, with an overall length of 110 mm (4.331 inches). The blade seats inserts with a 1.65 mm seat size and accommodates insert widths from 1.80 mm up to 2.40 mm. Maximum workpiece diameter is 1.38 inches. Installed by machinists and CNC tooling specialists, this blade is built to ISO 13399 standards.

The TGFS 0-17-2 is suited for grooving, parting, and turning applications where a neutral cutting direction is required. Its compact blade width and 17.2 mm cutting height make it appropriate for both shallow and moderately deep groove profiles on workpieces up to 1.38 inches in diameter. The Tang-Grip clamping system provides secure insert retention under high cutting forces typical in production turning environments. A wide range of compatible TAG inserts allows flexibility across various materials and finish requirements.

Key Features

• Single-end, neutral cutting direction for standard parting and grooving setups
• TGFS blade style in the Tang-Grip series with clamp-type insert holding
• Blade height of 17.2 mm (0.677 inches) and blade width of 1.65 mm (0.065 inches)
• Overall length of 110 mm (4.331 inches)
• Accepts TAG insert style, size code 2, with seat size of 1.65 mm
• Insert width range from 1.80 mm to 2.40 mm; maximum workpiece diameter of 1.38 inches
• Conforms to ISO 13399 tooling data standards

Compatibility

Compatible TAG inserts include: TAG L3C-15D, TAG L3C-6D, TAG L3J-15D, TAG L3J-6D, TAG L3JS-6D, TAG N3A, TAG N3C, TAG N3CB, TAG N3J, TAG N3JS, TAG N3JT, TAG N3LF, TAG N3M, TAG N3UT, TAG N3W, TAG R3C-15D, TAG R3C-6D, TAG R3C-8D, TAG R3J-6D, and TAG R3JS-6D.

Installation Notes

Installation is performed by qualified machinists or CNC tooling technicians. Ensure the machine spindle is fully stopped and the turret is de-energized before blade or insert changes. Use the correct torque driver for the clamp screw to avoid insert seat damage — refer to the ISCAR Tang-Grip tooling manual for the applicable fastener specification. Verify insert seating and clamping before resuming cutting operations.
