Irwin IR6954 Hex Die 16mm X 1mm 1-7/16 Inch Hcs

Product Description

The IRWIN IR6954 is a hex die used for cutting external threads on fasteners, studs, and round stock. It measures 16mm x 1mm, indicating a 16mm nominal thread diameter with a 1mm thread pitch. The die body is 1-7/16 inches in width, sized to fit a standard external die stock. Constructed from hardened high-carbon steel (HCS), the IR6954 delivers consistent thread-forming performance under the repetitive stress of threading operations. Licensed tradespeople and machinists use this die as a primary threading tool or to recut and restore damaged threads on existing hardware.

This die is suited for automotive repair and general machinery maintenance applications. It performs in situations where a technician needs to cut new threads or chase worn threads on bolts, rods, or shafts with a 16mm x 1mm metric thread profile. The 1-7/16 inch hex body seats securely in a matching external die stock, enabling controlled, repeatable thread cutting. Both shop professionals and field technicians working on metric-threaded components will find this a straightforward match for production and repair work alike.

Key Features

• 16mm x 1mm metric thread specification for precise external thread cutting
• 1-7/16 inch hex body fits standard external die stocks
• High-carbon steel (HCS) construction for durability under load
• Suitable for cutting new threads and restoring damaged threads
• Applicable to automotive repair and machinery maintenance tasks

Compatibility

Designed for use with standard external die stocks accepting a 1-7/16 inch hex die body; intended for 16mm x 1mm metric thread applications in automotive and machinery contexts.

Installation Notes

This die is installed by machinists or qualified tradespeople using a matching external die stock. Before threading, secure the workpiece firmly and apply appropriate cutting oil to reduce heat and extend die life. Start the die squarely on the stock to avoid cross-threading. Reverse the die periodically during threading to break chips and maintain thread quality.

Technical Specifications

• Thread Size: 16mm x 1mm
• Die Body Width: 1-7/16 inches
• Die Type: Hex External Die
• Material: High-Carbon Steel (HCS)
• UPC: 024721069542
• Sold As: Each

Standard Information

• Brand: IRWIN
• Manufacturer Part Number: IR6954
