Irwin IR6950ZR Hex Die 14x1.50

Product Description

The IRWIN IR6950ZR is a hex die designed for cutting external threads on fasteners and round stock. This die produces a 14x1.50 thread profile, making it suited for metric threading applications common in mechanical, plumbing, and industrial maintenance work. The hex body design allows for use with a standard die stock or hex wrench, providing a secure grip during thread cutting. Machinists, pipefitters, and maintenance technicians typically use this tool when chasing damaged threads or cutting new threads on rod, bolt, or pipe stock.

This hex die is used in shops and field settings where metric threading at a 14mm diameter with a 1.50mm pitch is required. It is well suited for repair and fabrication tasks on fasteners, studs, and threaded rod. The compact hex form makes it practical for confined-space thread work where a traditional round die stock may not fit. Trade professionals performing mechanical repairs, equipment maintenance, or custom fabrication will find this die a standard part of a threading kit.

Key Features

• 14mm diameter with 1.50mm thread pitch for metric threading applications
• Hex body design compatible with standard die stocks and hex wrenches
• Cuts clean external threads on rod, studs, and bolt stock
• Suitable for chasing damaged threads or cutting new threads in field and shop settings
• Sold individually, one die per unit

Compatibility

Designed as an OEM-style replacement or standard shop die for use in any die stock or holder that accepts a hex die body in the corresponding size for 14x1.50 metric thread cutting applications.

Installation Notes

Thread cutting with a hex die should be performed by a qualified machinist or tradesperson familiar with threading tools and proper technique. Secure the workpiece firmly before applying the die to prevent movement during cutting. Apply cutting oil to the die and workpiece to reduce heat, extend die life, and produce a cleaner thread. Inspect the die for wear or damage before each use and replace if teeth are chipped or dull.

Technical Specifications

• Thread Size: 14x1.50 metric
• Die Type: Hex Die
• Sold As: Each
• Minimum Order Quantity: 1
• UPC: 042526069505

Standard Information

• Brand: IRWIN
• Manufacturer Part Number: IR6950ZR
