IPS CORPORATION 83556 Test-Tite 3 Pneumatic Plug with 6 ft Chain

Product Description

The IPS CORPORATION 83556 is a Test-Tite pneumatic plug designed for testing drain, waste, and vent systems. This plug has a three-inch nominal size and features a durable rubber body with sealing ribs to prevent slippage. It includes a high-performance Schrader valve for easy inflation and comes with a six-foot galvanized steel chain.

• Nominal size of three inches.
• Includes a high-performance Schrader valve.
• Comes with a six-foot chain for secure handling.

Product Highlights

The pneumatic plug is ideal for drain, waste, and vent system testing, ensuring reliable sealing and easy inflation.

Product Information

Standard Information

• Product Code: 83556

Technical Specifications

• Nominal Size: 3 inches
• Chain Length: 6 feet
• Minimum Pipe Diameter: 2.25 inches
• Maximum Pipe Diameter: 3.25 inches
• Plug Diameter: 2.56 inches
• Plug Length: 3.45 inches
• Overall Plug Length: 4.57 inches
• Inflation Pressure: 35 psig
• Water Head: 30 feet
• Air Pressure: 13 psig
• Units per Case: 6
