Ipex 9847025 Cpvc Schedule 80 Socket Cap 2-1/2 in

Product Description

The IPEX 9847025 is a CPVC Schedule 80 socket cap designed to terminate pipe runs in industrial and commercial piping systems. Featuring a dome-head profile with a socket end connection, it is solvent-cemented in place to create a leak-free, pressure-rated seal. Manufactured from Corzan CPVC via injection molding to ASTM F439, it carries a pressure rating of 2000 psi at 73 degrees F and a temperature rating of 210 degrees F. The light gray finish indicates Schedule 80 wall thickness. Plumbers and pipefitters working in aggressive chemical or high-purity water environments install this fitting as a permanent end cap on branch and main lines.

This cap is suited for a range of demanding applications including chemical processing, industrial plating, chilled water distribution, deionized water lines, chemical drainage, and wastewater treatment systems. Its CPVC construction resists corrosion and chemical attack where metals and standard thermoplastics would degrade. The nominal pipe size is 2-1/2 inches. Packaged in quantities of five, it is a practical stocking item for contractors managing multiple system terminations on a single job. Compliance with ANSI/NSF 14/61 supports use in applications where material safety standards are required.

Key Features

• Dome-head socket end cap rated at 2000 psi at 73 degrees F
• Maximum temperature rating of 210 degrees F for hot process lines
• CPVC construction per ASTM F439 resists chemical attack and corrosion
• Injection-molded for consistent wall thickness and dimensional accuracy
• Meets ANSI/NSF 14/61 for safe use in water and chemical service
• Packaged in quantities of five for jobsite efficiency

Compatibility

Designed as an OEM-style replacement and standard fitting for 2-1/2-inch CPVC Schedule 80 piping systems installed per ASTM F439 specifications.

Installation Notes

Installation is performed by licensed plumbers or pipefitters qualified in thermoplastic piping systems. Depressurize and drain the line completely before cutting in or removing an existing cap. Use a CPVC-compatible solvent cement and primer applied per the cement manufacturer instructions and applicable plumbing code, such as the IPC or IFGC. Do not use pipe wrenches or mechanical force on the socket hub, as this can crack the fitting body.

Technical Specifications

• Nominal Size: 2-1/2 inches
• Schedule: 80
• End Connection: Socket
• Fitting Type: Dome Head Cap
• Material: CPVC
• Material Specification: ASTM F439
• Process: Injection Molded
• Pressure Rating: 2000 psi at 73 degrees F
• Temperature Rating: 210 degrees F
• Finish: Light Gray
• Applicable Standard: ANSI/NSF 14/61
• Packaging Quantity: 5
• Weight: 0.62 pounds
• Warranty: 1 Year Limited

Standard Information

• Brand: IPEX
• Manufacturer Part Number: 9847025
