Ipex 9835025 Cpvc Sch 80 Socket X Female Adapter 2.5 in

Product Description

The IPEX 9835025 is a 2-1/2 inch CPVC Schedule 80 socket x female threaded adapter designed for industrial and commercial piping systems handling corrosive fluids, high-purity water, and chemical process media. Injection molded from Corzan CPVC and conforming to ASTM F439, it delivers a pressure rating of 2000 PSI at 73 degrees F and a temperature rating of 210 degrees F. The light gray fitting transitions a plain-end socket connection to a female NPT thread, joining pipe runs where a threaded fitting or valve is downstream. Installation relies on solvent cementing the socket end and threading the female end directly to a compatible male-threaded component.

This adapter is suited for a wide range of demanding applications including chemical processing, chemical drainage, chilled water distribution, deionized water lines, industrial plating, and wastewater treatment systems. Its CPVC construction resists a broad spectrum of corrosive chemicals and maintains mechanical strength across a wide temperature range, making it appropriate for both above-ground and underground service. Licensed plumbers, pipefitters, and industrial maintenance technicians are the primary installers. Fittings are sold 5 per carton.

Key Features

• CPVC material conforming to ASTM F439 for chemical and high-purity fluid service
• 2000 PSI pressure rating at 73 degrees F with a 210 degrees F temperature rating
• Socket x female threaded end connection for flexible system integration
• Injection molded construction for consistent wall thickness and dimensional accuracy
• Compliant with ANSI/NSF 14 and NSF 61G standards
• Lightweight and maintenance-free once installed

Compatibility

Designed as an OEM-style Schedule 80 CPVC fitting for 2-1/2 inch piping systems requiring socket x female threaded transitions in chemical processing, industrial plating, deionized water, chilled water distribution, and wastewater treatment applications.

Installation Notes

Installation should be performed by a licensed plumber or qualified pipefitter following applicable codes such as ASTM and ANSI standards for thermoplastic piping. Isolate and depressurize the line and allow it to cool completely before cutting or disassembling any section. Apply the correct CPVC-rated solvent cement to the socket end following the cement manufacturer's instructions for cure time before returning the line to service. Do not over-torque the female threaded end, as CPVC is not rated for the same thread engagement forces as metal fittings.

Technical Specifications

• Size: 2-1/2 inches
• Schedule: 80
• End Connection: Socket x Female Threaded
• Material: CPVC
• Material Specification: ASTM F439
• Applicable Standard: ANSI/NSF 14/61G
• Pressure Rating: 2000 psi at 73 degrees F
• Temperature Rating: 210 degrees F
• Process: Injection Molded
• Finish: Light Gray
• Weight: 0.82 pounds
• Packaging Quantity: 5 per carton
• Warranty: 1 Year Limited

Standard Information

• Brand: IPEX
• Manufacturer Part Number: 9835025
