Ipex 36690 Pvc Sch 80 Spigot X Female Bushing 1-1/4x1 in

Product Description

The IPEX 36690 is a PVC Schedule 80 spigot x female bushing designed to reduce a 1-1/4 inch line down to a 1 inch fitting connection. Built to Schedule 80 dimensional and pressure standards, this bushing is suited for industrial piping systems where chemical resistance and long service life are required. It is manufactured from high-performance PVC that resists oxidation, creep stress, and photodegradation. The smooth interior bore maintains flow efficiency over the life of the installation. Licensed plumbers and pipefitters install this fitting in chemical process, industrial, and potable water distribution systems.

This bushing is used in residential, commercial, and industrial PVC Schedule 80 piping systems. Typical applications include chemical process lines, industrial fluid handling, and potable water distribution where a spigot-to-female threaded or socket reduction is needed. The spigot end inserts into a standard Schedule 80 socket fitting, while the female end accepts a 1 inch spigot or pipe end. It is part of the IPEX Xirtec PVC system, which is engineered and manufactured to consistent dimensional and performance standards across pipe, valves, and fittings.

Key Features

• Outstanding resistance to most acids, alcohols, alkalis, salt solutions, and halogens
• Listed for potable water service with NSF and CSA International
• Resists rust, pitting, scaling, and corrosion for a consistently smooth bore over time
• Manufactured with significantly less energy than equivalent steel or steel alloy fittings
• Engineered to Schedule 80 dimensional standards for consistent fitment across IPEX system components

Compatibility

Designed for use within the IPEX Xirtec PVC Schedule 80 piping system. Functions as a spigot x female bushing reducing 1-1/4 inches to 1 inch in standard PVC Schedule 80 pipe and fitting assemblies.

Installation Notes

Installation should be performed by a licensed plumber or pipefitter in accordance with applicable local plumbing codes and IPC guidelines. Shut off and depressurize the piping system before beginning any fitting work. Use a compatible PVC solvent cement rated for Schedule 80 fittings and follow manufacturer cure time requirements before restoring pressure. Do not over-ream or damage the socket seat, as this can compromise the integrity of the solvent-welded joint.

Technical Specifications

• Material: PVC
• Schedule: Schedule 80
• Connection Type: Spigot x Female
• Inlet Size: 1-1/4 inches
• Outlet Size: 1 inch
• Certifications: NSF Listed, CSA International

Standard Information

• Brand: IPEX
• Manufacturer Part Number: 36690
