Ipex 36355 Pvc Schedule 80 2-piece Flange 8 in

Product Description

The IPEX 36355 is an 8-inch PVC Schedule 80 two-piece flange fitting designed for industrial and commercial piping systems. Built to Schedule 80 dimensional and pressure standards, this flange provides a robust, corrosion-resistant connection point in PVC pipeline assemblies. It handles a maximum service temperature of 140 degrees F under pressure conditions and up to 180 degrees F during intermittent gravity flow. Licensed plumbers and industrial pipefitters install this fitting in chemical process lines, water treatment systems, and general industrial fluid handling applications where metal flanges are impractical or cost-prohibitive.

The 36355 is suited for industrial process piping, chemical distribution lines, and potable water systems. Its interior surface remains smooth across virtually all service conditions, resisting rust, pitting, scale, and corrosion. This fitting is listed with the National Sanitation Foundation (NSF) and CSA International for use with potable water, making it applicable in both process and water service installations. It performs reliably with a broad range of acids, alcohols, alkalis, salt solutions, and halogens.

Key Features

• Schedule 80 PVC construction rated for demanding pressure and industrial service
• Maximum service temperature of 140 degrees F under pressure; 180 degrees F for intermittent gravity flow
• Smooth interior bore resists rust, pitting, scale, and corrosion throughout service life
• Chemical resistance to most acids, alcohols, alkalis, salt solutions, and halogens
• NSF and CSA International listed for potable water service
• Two-piece flange design simplifies installation and future disassembly in flanged systems

Compatibility

Designed as an OEM-compatible Schedule 80 PVC flange fitting for 8-inch PVC piping systems in industrial chemical process, water treatment, and general fluid handling applications.

Installation Notes

Installation should be performed by a licensed plumber or qualified industrial pipefitter in accordance with applicable plumbing codes and the IPEX installation guidelines for Schedule 80 PVC systems. Depressurize and drain the piping system completely before removing or installing flanged components. Use only compatible PVC solvent cement and primer rated for Schedule 80 applications; do not use adhesives intended for Schedule 40 only. Bolt torque should follow flange gasket and fastener manufacturer recommendations to avoid cracking the flange hub.

Technical Specifications

• Size: 8 inches
• Material: PVC
• Schedule: Schedule 80
• Fitting Type: 2-Piece Flange
• Max Service Temperature (Pressure): 140 degrees F (60 degrees C)
• Max Service Temperature (Intermittent Gravity Flow): 180 degrees F (82 degrees C)
• Certifications: NSF Listed, CSA International Listed

Standard Information

• Brand: IPEX
• Manufacturer Part Number: 36355
