Ipex 300200prb Pvc Sch40 Reducer Bushing 3x2 Inch

Product Description

The IPEX 300200prb is a PVC Schedule 40 conduit reducer bushing designed to transition a 3-inch bell fitting down to a 2-inch spigot connection. This bell-to-spigot configuration allows electricians and conduit installers to reduce conduit run diameter within a raceway system without additional adapters. Constructed from non-metallic PVC, the bushing resists corrosion and is suited for underground, direct burial, and above-grade conduit installations where Schedule 40 fittings are specified.

This reducer bushing is used in electrical conduit systems where a change in conduit size is required between sections of a run. Typical applications include transitioning between main conduit trunks and branch conduit runs in residential, commercial, and light industrial wiring installations. The bell-end receives the larger conduit, while the spigot end inserts into a compatible 2-inch fitting or conduit section, providing a secure solvent-cement joint.

Key Features

• Bell-to-spigot configuration enables direct in-line conduit size reduction
• PVC Schedule 40 construction offers corrosion resistance for wet and dry locations
• Non-metallic material eliminates galvanic corrosion concerns in mixed-material installations
• Solvent-cement joining method provides a permanent, watertight connection
• Compatible with standard PVC Schedule 40 conduit fittings and pipe

Compatibility

Designed as an OEM-style fitting for use with PVC Schedule 40 electrical conduit systems requiring a 3-inch bell to 2-inch spigot reduction.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and applicable local codes. De-energize all circuits in the conduit run before beginning any fitting work. Use the appropriate PVC conduit solvent cement and primer for a code-compliant joint. Allow full cure time before pulling wire or pressurizing the conduit system.

Technical Specifications

• Material: PVC (Non-Metal)
• Type: Bell to Spigot Reducer Bushing
• Inlet Size: 3 inches (Bell)
• Outlet Size: 2 inches (Spigot)
• Schedule: Schedule 40
• UPC: 98006006231

Standard Information

• Brand: IPEX
• Manufacturer Part Number: 300200prb
