Io Hvac Controls SC-T32-P Programmable Thermostat 3H/2C

Product Description

The IO HVAC CONTROLS SC-T32-P is a universal 7-day programmable thermostat designed for residential and light commercial heating and cooling systems. It supports up to 3 stages of heating and 2 stages of cooling, making it suitable for multi-stage heat pump and conventional forced-air applications. The SC-T32-P provides flexible day-by-day scheduling across a full 7-day cycle, allowing precise temperature management throughout the week. Licensed HVAC technicians install this thermostat as a direct replacement or new-installation control device in low-voltage system wiring configurations. The unit measures 5.125 x 2.375 x 6.75 inches and weighs 0.9 pounds.

The SC-T32-P fits typical residential and light commercial forced-air systems requiring multi-stage thermostat control. Its universal design makes it applicable across a broad range of gas, oil, and electric furnace configurations, as well as conventional and heat pump systems with up to 3 heat and 2 cool stages. It is commonly installed during system upgrades, thermostat replacements, or new construction where programmable scheduling and multi-stage compatibility are required.

Key Features

• Supports 3 stages of heating and 2 stages of cooling for multi-stage system compatibility
• 7-day programmable scheduling with independent day-by-day temperature control
• Universal design compatible with conventional and heat pump forced-air systems
• Compact form factor at 5.125 x 2.375 x 6.75 inches for standard wallplate mounting
• Lightweight construction at 0.9 pounds for straightforward wall installation

Compatibility

Designed as an OEM-style universal replacement thermostat for residential and light commercial low-voltage forced-air heating and cooling systems requiring 3H/2C multi-stage control.

Installation Notes

Installation of the SC-T32-P should be performed by a licensed HVAC technician following local codes and manufacturer wiring diagrams. Power down the system at the breaker or disconnect before removing the existing thermostat and handling low-voltage wiring. Label all wires at the old thermostat before disconnecting to ensure correct termination at the new control. Refer to local mechanical and electrical codes, including NEC guidelines, for any applicable low-voltage wiring requirements.

Technical Specifications

• Stages: 3 Heat / 2 Cool
• Scheduling: 7-Day Programmable
• Dimensions (W x H x D): 5.125 x 2.375 x 6.75 inches
• Weight: 0.9 pounds

Standard Information

• Brand: IO HVAC CONTROLS
• Manufacturer Part Number: SC-T32-P
