Io Hvac Controls SC-T-OTS Outdoor Temperature Sensor

Product Description

The IO HVAC CONTROLS SC-T-OTS is an outdoor temperature sensor designed to work with SC-T32 Series thermostats. It provides accurate ambient outdoor temperature readings to the thermostat control system, enabling outdoor reset and temperature-based logic functions. The sensor is compact, measuring 0.75 x 0.75 x 1.75 inches, and weighs 2.7 pounds. Installation is handled by HVAC technicians as part of a thermostat commissioning or upgrade project. Its small profile makes it suitable for mounting in standard outdoor sensing locations while remaining unobtrusive on the structure.

This sensor is intended for use with IO HVAC CONTROLS SC-T32 Series thermostat installations in residential and light commercial HVAC applications. It connects to the thermostat to supply outdoor temperature data, which the control system uses to optimize heating and cooling operation. Typical installations involve routing low-voltage sensor wiring from the outdoor mounting location back to the thermostat or control panel.

Key Features

• Designed specifically for use with SC-T32 Series thermostats
• Compact housing at 0.75 x 0.75 x 1.75 inches for discreet outdoor mounting
• Provides real-time outdoor ambient temperature input to the thermostat system
• Supports outdoor reset and temperature-based control logic

Compatibility

Designed for use with IO HVAC CONTROLS SC-T32 Series thermostats as the dedicated outdoor temperature sensing accessory.

Installation Notes

Installation should be performed by a licensed HVAC technician. Power down the thermostat system before connecting or disconnecting the sensor wiring. Mount the sensor in a shaded, outdoor location away from direct sunlight and heat sources to ensure accurate temperature readings. Follow all applicable local codes and manufacturer wiring guidelines when routing low-voltage sensor leads.

Technical Specifications

• Width: 0.75 inches
• Height: 0.75 inches
• Depth: 1.75 inches
• Weight: 2.7 pounds

Standard Information

• Brand: IO HVAC CONTROLS
• Manufacturer Part Number: SC-T-OTS
