iO HVAC Controls HD-2616 26 Inch X 16 Inch Two-Position Rectangular Motorized Zone Damper Replacement for Honeywell ZD26X16TZ

Product Description

The iO HVAC Controls HD-2616 is a 26 inch by 16 inch two-position rectangular motorized zone damper, designed for efficient zone control in HVAC systems. This product is a direct replacement for Honeywell ZD26X16TZ, EWC ND-RSD2616, Zone First ZDS-2616, and Braeburn 112616 models.

• Constructed from durable 1/16 inch extruded aluminum with parallel blades and mounting flange.
• Features a 24 Volt, 10 VA, 0.43 Amp powered closed, spring return open actuator, offering reliable operation.
• Engineered for low-maintenance performance with nylon bushings and impedance-protected motor without end switches.

Product Highlights

This damper supports installation flexibility, being mountable in any position and compatible with most 24V zoning and ventilation controls. With a simplistic design for limited position adjustments, it is suitable for duct systems with static pressures up to 1.0 inches WC.

Product Information

Standard Information

• Brand: iO HVAC Controls
• MPN: HD-2616

Technical Specifications

• Dimensions: 26 inches width x 16 inches height
• Material: Extruded Aluminum
• Electrical Specs: 24 Volt, 10 VA, 0.43 Amp
• Warranty: 5 years
