Product Description
The INTERTHERM AG3000 is a 120/240V AC 100 kA HVAC Surge Protective Device designed for protecting HVAC equipment from damaging power surges. This device is essential for safeguarding your heating and cooling systems, which often go unprotected while electronics are shielded. Installation is straightforward, and a green LED indicator shows the protection status. The AG3000 uses advanced TPMOV technology, which minimizes risks associated with standard MOVs. It meets UL standards, ensuring reliable performance.
- 3 modes of protection - L-G, L-L, L-N
- TPMOV surge protection technology
- Type 4X watertight and UV-resistant plastic enclosure
Product Highlights
This surge protective device is ideal for use with boilers, heat pumps, and air handlers, ensuring they operate safely even during power fluctuations.
Product Information
Standard Information
-
Product Type: HVAC Surge Protective Device
-
Catalog Number: AG3000
Technical Specifications
-
Height: 3.875 inches
-
Weight: 1 lb.
-
Maximum Operating Temperature: +70 degrees C
-
Minimum Operating Temperature: -40 degrees C
-
For Use With: Boilers, Heat Pumps, Furnaces, Air Handlers
-
Specifications Met: UL Listed, cULus Listed
