International Comfort Products FTMA5B48L0CA QuietComfort TXV Variable Speed Fan Coil 4 ton Nominal

Product Description

The INTERNATIONAL COMFORT PRODUCTS FTMA5B48L0CA is a premium air handler, branded as Comfortmaker or Tempstar, combining ICP fan coil technology with environmentally balanced R-454B refrigerant. This 4 ton nominal unit features a variable speed ECM motor, achieving operational advantages when paired with a heat pump or air conditioner using R-454B refrigerant. It operates on 208/230V, 1 phase, 60 Hz, and has a 3/4 hp motor.

• Premium air handler design for HVAC systems
• Utilizes environmentally balanced R-454B refrigerant
• Features a variable speed ECM motor for operational efficiency

Product Highlights

Premium air handler with R-454B refrigerant and variable speed ECM motor.

Product Information

Standard Information

• Brand: INTERNATIONAL COMFORT PRODUCTS
• Manufacturer Part Number: FTMA5B48L0CA

Technical Specifications

• Cooling Capacity: 48,000 Btu/hr
• Flow Rate: 1400 cfm
• Refrigerant Type: R-454B
• Voltage Rating: 208 / 230 V
• Filter Size: 20 x 20 in
• Motor HP: 3/4 HP
• Motor Type: ECM
• Series: FTMA5
• Configuration: Multi-Position
• A2L Compatible: Yes
• Coil Type: Multi
• Material: Aluminum
• Minimum Circuit Ampacity (MCA): 7.1
• Refrigerant Control: TXV
• Suction Line (OD): 7/8
• Tonnage: 4 Ton
• UL Listed: Yes
• Air Handler Type: Modular (2-Piece)
• Thermostat: 24V
• Cooling Stages: Two
• Liquid Line (OD): 3/8
• Return Air Opening: 19-1/8" x 19-13/16" in.
• Supply Air Opening: 19-1/4" x 11" in.
