Intermatic T7802B 7-Day Mechanical Time Switch 208-277VAC

Product Description

The Intermatic T7802B is an advanced mechanical time switch designed for 7-day scheduling of electrical circuits across varying applications. This unit provides distinct daily programs with minimum ON/OFF times of 3.5 hours, ensuring reliable performance for both light and heavy electrical loads. Ideal for industrial, commercial, and HVACR applications, it supports 208 to 277 voltage and features a DPDT contact type.

• True 7-day load control for precise management of operational schedules.
• Dual NO/NC contact configuration for versatile wiring options.
• Rugged NEMA 1 steel enclosure tailored for indoor use enhances durability.

Product Highlights

Equipped with separate terminals for switching loads not on-line voltage, this time switch ensures flexibility and efficiency within electrical frameworks. Thanks to its mechanical design, it handles up to 40A per circuit with a straightforward manual interface, minimizing setup complexity.

Product Information

Standard Information

• Brand: Intermatic
• Model: T7802B
• Type: Electromechanical
• Enclosure: NEMA 1 Steel

Technical Specifications

• Contact Type: DPDT
• Operational Voltage: 208-277 VAC
• Number of Poles: 2 Pole
• Mounting Type: Wall Mount
• Dimensions: 12.63 inches x 4.13 inches x 9.31 inches
• Weight: 7.85 pounds
