Intermatic T1905HD 24-Hour Heavy-Duty Metal Dial Mechanical Time Switch 125 VAC

Product Description

The Intermatic T1905HD is a heavy-duty mechanical timer switch designed for demanding environments. It features fully encapsulated motors to keep dust and debris out. The ON/OFF trippers are securely attached to the metal dial, eliminating the risk of loss. This timer provides 15-minute intervals, allowing for up to 96 operations every day.

• 15-minute interval operations
• Permits up to 96 operations (48 ON/48 OFF) daily
• SPDT contact, wall mounting

Product Highlights

This timer is suitable for pool and spa control, HVAC systems, and various indoor applications. It is built to withstand harsh conditions and features a NEMA 1 enclosure.

Product Information

Standard Information

• Catalog Number: T1905HD
• Brand: Intermatic

Technical Specifications

• Type: Heavy Duty
• Voltage: 125 VAC
• Wattage: 3 W
• Height: 7-7/8 inches
• Width: 5-1/8 inches
• Depth: 3-7/16 inches
• Action: SPDT
• Operating Temperature: -40 to +165 degrees F
