Product Description
The Intermatic MIL72ASWUZ-120 is a reliable electromechanical timer designed for precise time control in various applications. Engineered for both DIN rail and surface mounting, this timer facilitates 7-day programming with a clear analog display for straightforward settings adjustments.
- Equipped with synchronous drive technology ensuring consistent performance.
- Suitable for a wide temperature range from minus forty degrees to one hundred eighty-five degrees Fahrenheit.
- Sturdy plastic enclosure with dust cover protects internal mechanisms.
Product Highlights
This timer is ideal for controlling lighting, HVACR systems, pumps, and motors. It supports multiple switching operations with a 21 amp at 120 to 250 VAC, capable of handling 1 horsepower at 125 VAC and 2 horsepower at 250 VAC.
Technical Specifications
-
Power Requirement: 120 VAC
-
Current Rating: 21 A
-
Control Type: 1NO-1NC 1SPDT Contact Form
-
Operating Temperature: minus forty to one hundred eighty-five degrees Fahrenheit
-
Dimensions: 2.83 in L x 2.06 in W x 4 in H
-
Mounting Options: DIN Rail/Surface
-
Certifications: CE, cCSAus, cULus Listed
