Intermatic ET2725C NEMA 1 Steel Case 7-Day 120 to 277 VAC 60 Hz 30 Amp DPST Electronic Control

Product Description

The Intermatic ET2725C is a digital timer control operating at 120 to 277 VAC. This unit features a maximum of 30 Amp, double pole single throw (DPST) for efficient load management. It is designed for various scheduling tasks, offering robust performance in indoor settings.

• Configurable outputs for various applications
• 100-hour backup without battery
• Up to 96 ON/OFF events

Product Highlights

The ET2000 Series combines simplicity with detailed scheduling capabilities, making it adaptable for many situations, including indoor lighting control and machinery operation. The device allows users to create a schedule that includes holiday blocks and can manage complex timing needs effectively.

Product Information

Standard Information

• Brand: Intermatic
• Country of Origin: Mexico

Technical Specifications

• Catalog Number: ET2725C
• Amperage Rating: 30 Amp
• Input Voltage: 120-277 VAC
• Contact Configuration: 1 NO
• Number of Poles: 1 Pole
• Enclosure: Type 1 Steel
• Temperature Rating: -40 to 155 degrees F
• Width: 5.125 inches
• Height: 7-7/8 inches
• Depth: 3.437 inches
• Timing Range: 1 minute to 6 days, 23 hours, 59 minutes
