Intermatic EK4235S Nightfox Stem and Swivel Mount Electronic Photocontrol 480VAC 1/2 Inch-14 NPSM Threaded Stem

Product Description

The INTERMATIC EK4235S Nightfox electronic photocontrol is designed for permanent installation on outdoor electrical boxes or outdoor lighting fixtures. It is ideal for LED fixtures with long-life expectations, providing reliable dusk-to-dawn functionality. This unit features a 1/2"-14 NPSM threaded stem, fitting standard outlet boxes and wall packs with a minimum 7/8" diameter installation hole, and includes 9" wire leads for connection.

• NIGHTFOX electronic photocontrols permanently install on outdoor electrical boxes or outdoor lighting fixtures
• Ideal for LED fixtures with long-life expectations
• 1/2”-14 NPSM threaded stem fits standard outlet boxes and wall packs with a minimum installation hole size of 7/8” diameter

Product Highlights

Features a non-drift silicon light sensor, DC relay with zero-crossing circuitry for extended life, and exceeds 10,000 ON/OFF switching cycles, making it LED compatible.

Product Information

Standard Information

• Brand: INTERMATIC
• Manufacturer Part Number: EK4235S
• Country of Origin: Mexico

Technical Specifications

• Type: Swivel Photocells
• Sensor: Silicon Diode
• Mounting: Stem and Swivel
• Standard: UL
• Connection: Wire leads
• Input Voltage: 480 VAC
• Frequency Rating: 50/60 Hertz
• Operating Temperature: -40°F to 158°F
• Environmental Conditions: Wet/Dry Location
• Enclosure Material: Polycarbonate
• Applications: parking lot lighting; landscape lighting; exterior lighting; street lighting; pedestrian pathway
• TC Connection: Color Coded Lead
• Operating Cycles: 10k
• Power Consumption: <0.5 WTT @ 277 VAC
• Current: 0.350 Amps
• Standards: California Proposition 65
• Light Technology: LED
• Max Load Wattage: 1000 Watt
• Control Type: Dusk to Dawn Light Control
• Current Type: AC
