Ingersoll Rand 666101-244-C Diaphragm Pump Pro Series 35 gpm (1\") 341VZ9

Product Description

The Ingersoll Rand 666101-244-C is an ARO Pro Series air-operated double-diaphragm (AODD) pump for industrial fluid handling. It features a 1" metallic liquid end with an aluminum center body, stainless steel fluid caps and manifold, PTFE/Santoprene diaphragms, PTFE valve balls, and 316 stainless steel seats. The pump delivers up to 35 gpm at 120 psi, supports a 20 ft suction lift, and handles suspended solids to 1/8".

• Aluminum center body with stainless steel fluid caps and single stainless steel manifold; stainless hardware
• PTFE/Santoprene diaphragms, PTFE valve balls, and 316 stainless steel seats for chemical compatibility
• Performance: up to 35 gpm (133 LPM), maximum working pressure 120 psi (8.3 bar), maximum suction lift 20 ft (6.1 m)

Product Highlights

1" AODD pump, 35 gpm, 120 psi, PTFE/Santoprene diaphragms, handles 1/8" solids

Product Information

Standard Information

• Brand: INGERSOLL RAND
• Manufacturer Part Number: 666101-244-C
• Country of Origin: USA

Technical Specifications

• Brand: Ingersoll Rand
• MPN: 666101-244-C
• Type: Air-operated double-diaphragm (AODD) pump
• Series: 1" Metallic Pro Series
• Center Body Material: Aluminum
• Fluid Caps/Manifold Material: Stainless steel (single manifold)
• Hardware: Stainless steel
• Diaphragm Material: PTFE / Santoprene
• Valve Balls Material: PTFE
• Seats Material: 316 stainless steel
• Maximum Flow: 35 GPM (133 LPM)
• Displacement Per Cycle: 0.16 Gal (0.60 L)
• Maximum Working Pressure: 120 psi (8.3 bar)
• Ratio: 1:1
• Air Inlet: 1/4" female NPT
• Fluid Connection Size: 1"
• Connection Type: 1 - 11-1/2 NPTF (1")
• Solids Max Diameter: 0.125" (3.2 mm)
• Max Suction Lift: 20 feet (6.1 m)
• Temperature Range: 40 to 225 F (4 to 107 C)
• Sound Level: 70 dBA
• Suspended Solids Max Diameter: 0.125" (3.2 mm)
• Cross Reference: 341VZ9
• Country of origin: US
• Dimensions (H x L x W): 31.5 x 21.84 x 15.49
• Weight (manufacturer spec): 16.8525 lbs
