Ingersoll Cutting Tools 5873349 Sngs Milling Insert IN2505

Product Description

The INGERSOLL CUTTING TOOLS 5873349 is a solid carbide milling insert designed for high-performance metal removal in demanding machining applications. Built to ANSI and ISO standards under the SNGS series, this insert features a square shape with a neutral hand orientation and a negative rake geometry. It carries a dual-layer TiAlN and TiN coating applied via PVD process, which supports heat resistance and edge durability across a range of workpiece materials. The insert measures 0.5 inches in length and width, with a thickness of 0.25 inches, and delivers two cutting edges per insert on a double-sided body. A corner radius of 0.0472 inches (3/64 inch) provides a rounded cutting edge style suitable for general milling work.

This insert is suited for milling steel, stainless steel, cast iron, superalloys, titanium, and hard materials, covering ISO material codes P, M, K, S, and H. It is appropriate for use in both production and job-shop environments where a broad material range is required without changing tooling. The insert is held by screw-clamp mounting and is compatible with the DN5H cutter series. Machinists and CNC operators working in shops handling mixed-material production runs will find the IN2505 micrograin carbide grade and W chip breaker geometry well-matched to their requirements.

Key Features

• Solid micrograin carbide substrate for edge toughness and wear resistance
• TiAlN and TiN dual-layer PVD coating for thermal protection and extended tool life
• Double-sided insert body with 2 cutting edges per insert
• Square SNGS insert style with negative rake and 90-degree included angle
• W chip breaker geometry for improved chip control across multiple materials
• Neutral hand orientation for flexible cutter positioning

Compatibility

Compatible with the DN5H cutter series. ANSI and ISO code: SNGS1205ANN-W IN2505. Designed as an OEM-style replacement or standard supply insert for SNGS-series milling cutters accepting screw-held square inserts in the 1205 insert size.

Installation Notes

Installation is performed by qualified machinists or CNC tooling technicians. Always power down and lock out the machine spindle before changing inserts. Use the appropriate Torx or hex key as specified by the cutter body manufacturer when seating the clamping screw. Inspect the cutter pocket and seating surface for debris or damage before inserting a new blade to ensure proper seating and runout.
