Ingersoll Cutting Tools 5803398 Milling Insert APKT160432R

Product Description

The INGERSOLL CUTTING TOOLS 5803398 is a solid carbide milling insert carrying ISO designation APKT160432R and manufacturer grade IN2030. It features a parallelogram insert shape with an 85-degree included angle, a positive rake geometry, and a sharp cutting edge style. The TiAlN coating is applied via PVD process over a coarse-grain solid carbide substrate, delivering thermal and wear resistance during interrupted and continuous milling cuts. With two cutting edges and a right-hand orientation, this insert is suited for face milling and shoulder milling operations across a range of ferrous and exotic workpiece materials. Licensed HVAC, plumbing, and electrical installers are not the audience here - this part is installed by machinists and CNC operators in metal-cutting environments.

This insert is designed for milling steel, stainless steel, cast iron, superalloys, and titanium workpiece materials - corresponding to ISO material codes P, M, K, and S. It is held in the cutter body by a screw-clamp method and is compatible with Ingersoll cutter series 12J1B, 22J3B, 22J5B, 23J6G, and 2J1B. The single-sided configuration and common chip breaker geometry make it a versatile choice for general-purpose milling on CNC machining centers handling a wide cross-section of workpiece materials.

Key Features

• ISO code APKT160432R and ANSI code APEB53R04 IN2030 for cross-reference ordering
• TiAlN coating applied by PVD process over coarse-grain solid carbide substrate
• Positive rake and sharp cutting edge style reduce cutting forces on difficult materials
• Right-hand orientation with 2 usable cutting edges per insert
• 11-degree relief angle supports clearance in both face and shoulder milling applications
• Compatible with P, M, K, and S ISO material classifications including superalloys and titanium

Compatibility

Compatible with Ingersoll cutter series 12J1B, 22J3B, 22J5B, 23J6G, and 2J1B. Screw-clamp insert holding method. Conforms to ANSI and ISO standards for parallelogram milling inserts.

Installation Notes

Installation is performed by a machinist or CNC setup technician. Always power down and lock out the machine spindle before seating or replacing inserts. Use the correct torque wrench and manufacturer-specified insert screw to secure the screw-clamp holding method - do not over-torque or substitute fasteners. Inspect the insert pocket and seating surface for chips or debris before installation to ensure proper seating and runout.
