Product Description
ILSCO SPA-350 is a dual rated aluminum splicer/reducer designed for conductor ranges from ten to three hundred fifty kcmil. This product is suitable for use with both aluminum and copper conductors and manufactured from high-strength aluminum alloy.
- Electro-tin plated for low contact resistance
- Facilitates ease of installation with chamfered wire entry
- Compact design with large screw diameters for secure fastens
Product Highlights
The SPA-350 provides application versatility and ensures secure contact among wire strands. It prevents dissimilar metals from coming into contact, ensuring reliability in electrical connections.
Product Information
Standard Information
-
Catalog Number: SPA-350
-
Manufacturer: ECM Industries
-
Brand: ILSCO
Technical Specifications
-
Body Material: Electro-Tin Plated High Strength 6061-T6 Aluminum Alloy
-
Conductor Material: Aluminum/Copper
-
Hex Size: Five Sixteenth Inch
-
Maximum Conductor Size: 350 KCMIL
-
Minimum Conductor Size: 10 AWG
-
Number Of Screws: 2
-
Voltage Rating: 2000 VAC
-
Approval: UL 453G, UL 486A/B, CSA
