Product Description
The ILSCO PDB-11-350-1 is a power distribution block designed for dual rating with a line conductor range of three hundred fifty to six AWG and a load range of three hundred fifty to six AWG. This product provides one port per pole on both the line side and the load side, ensuring versatility in electrical applications.
- Rated for both copper and aluminum conductors.
- Features lay-in primary ports allowing two primary conductors to feed through without breaking the main feeder cable.
- Constructed with a Valox insulating base for impact resistance and insulating qualities.
Product Highlights
This device is ideal for simplifying electrical installations requiring multiple conductor ranges. It is compliant with UL and CSA standards.
Product Information
Standard Information
-
Catalog Number: PDB-11-350-1
-
Manufacturer: ECM Industries
Technical Specifications
-
UPC: 783669710793
-
Country of Origin: Mexico
-
Width: 1.843 inches
-
Height: 2.625 inches
-
Length: 4 inches
-
GTIN: 00783669710793
-
Series: PDB Series
-
ECCN: EAR99
