ILSCO PBTS-4-1/0 Multi-Tap Connector, Insulated, 4 Ports, Single Sided Entry, Tin Plated, UL, CSA

Product Description

The ILSCO PBTS-4-1/0 is an insulated multi-tap connector designed for use with copper or aluminum conductors. This connector features four ports, allowing for multiple connections from a single point. It accommodates conductors ranging from one aught to sixteen. The connector is suitable for applications requiring a voltage of up to six hundred volts.

• Compatible with conductors from one aught to fourteen AWG
• Made of tin-plated aluminum for enhanced conductivity
• UL and CSA certified for safety and reliability

Product Highlights

This multi-tap connector is ideal for expanding conductor connections in electrical systems. The insulated design prevents accidental contact with conductive surfaces.

Product Information

Standard Information

• Catalog Number: PBTS-4-1/0
• Manufacturer: ECM Industries
• Brand: ILSCO
• Country of Origin: Mexico
• UPC: 783669079289

Technical Specifications

• Volts AC: 600
• Conductor Range: 1/0 - 14 AWG
• Ports: 4
• Type: Insulated Connector Block
• Material: Aluminum with Plastisol
• Color: Black
• Gauge Options: 12, 2, 10, 1, 14, 6, 4, 1/0, 3, 8
