ILSCO PBTS-2-1/0 Nimbus Insulated Aluminum Multi-Tap Connector, Conductor Range 1/0-14, 2 Ports, Single Sided Entry, Tin Plated, UL, CSA

Product Description

The ILSCO PBTS-2-1/0 is a durable multi-tap connector designed for aluminum and copper conductors. This connector is suitable for conductor ranges from fourteen to one over zero AWG. It features a single-sided entry and is UL and CSA approved.

• Conductors: Aluminum and Copper, with sizes ranging from fourteen to one over zero AWG.
• Approval: UL 453G, UL 486A/B, and CSA certified.
• Designed with high dielectric strength plastisol for improved reliability.

Product Highlights

Connector designed for flexibility in installation. Prevents oxide formation with entry port closures.

Product Information

Standard Information

• Manufacturer: ECM Industries
• Country of Origin: Mexico
• UPC: 783669079241

Technical Specifications

• Catalog Number: PBTS-2-1/0
• Maximum Conductor Size: 1/0 AWG
• Minimum Conductor Size: 14 AWG
• Number of Ports: 2
• Temperature Rating: -45 to 90 degrees Celsius
• Voltage Rating: 600 VAC
• Body Material: High Dielectric Strength Plastisol
