Ilsco PBTD-5-750 Multi-Tap Connector Power (1) Replacement MPN

Product Description

The Ilsco PBTD-5-750 is a multi-tap connector designed for reliable electrical connections. This connector supports a broad wire range, from seven hundred fifty KCMIL to two hundred fifty KCMIL. It is a dual-rated product, suitable for copper or aluminum conductors.

• Broad wire range from seven hundred fifty KCMIL to two hundred fifty KCMIL.
• Dual rated for copper or aluminum conductors.
• UL listed and CSA certified for six hundred volts, ninety degrees Celsius.

Product Highlights

This connector is made from high dielectric strength plastisol, ensuring chemical resistance and a robust structure. Its versatility allows for flexibility in electrical applications.

Product Information

Standard Information

• Manufacturer: Ilsco
• UPC: 783669078725

Technical Specifications

• Approval: UL 453G, UL 486A/B, CSA
• Body Material: High dielectric strength plastisol insulated
• Cable Entry: Two side entry
• Conductor Material: Copper/Aluminum
• Maximum Conductor Size: 750 KCMIL
• Minimum Conductor Size: 250 KCMIL
• Number of Ports: 5
• Product UPC: 783669078725
