ILSCO CT-600 SureCrimp Copper Compression Sleeve, 600 kcmil, UL, CSA

Product Description

The ILSCO CT-600 is a copper compression sleeve designed for conductor size six hundred kcmil. This product is manufactured by ECM Industries and is UL and CSA listed. The sleeve is designed to provide reliable connections for electrical applications.

• Constructed with high strength seamless copper tubing.
• Tin plated for enhanced corrosion resistance.
• Suitable for high voltage applications up to thirty-five kilovolt.

Product Highlights

This compression sleeve is suitable for use in splicing, reducing, grounding, and bonding applications. Its reliable design ensures low contact resistance and maximum conductivity.

Product Information

Standard Information

• Brand: ILSCO
• Manufacturer: ECM Industries

Technical Specifications

• Catalog Number: CT-600
• Conductor Size: 600 kcmil
• Conductor Type: Copper
• Connector Type: Crimp
• Country of Origin: Mexico
• Length: 2-7/8 inches
• Dimensions: 0.92 inches ID x 1.187 inches OD
• Finish: Electro-Plated Tin
• Temperature Rating: 90 degrees Celsius
• Voltage Rating: 600 VAC
• Mfg Standards/Approvals: ARRA Compliant, UL 486A-B, CSA File No. LR29601
