ILSCO CT-500 Surecrimp Copper Compression Sleeve, 500 KCMIL Copper Conductor

Product Description

The ILSCO CT-500 Surecrimp Copper Compression Sleeve is designed for use with copper conductors. It is suitable for wire sizes ranging from five hundred KCMIL to two hundred fifty KCMIL. The compression sleeve is ideal for grounding and bonding applications. This product ensures a secure connection and is reliable for high voltage uses.

• Manufactured from high strength seamless copper tubing.
• Electro-tin plated for enhanced durability.
• Suitable for high voltage applications up to thirty-five kV.

Product Highlights

This compression sleeve provides low contact resistance, maximum conductivity, and excellent crimping characteristics. It assures easy conductor insertion and ensures maximum cable insertion.

Product Information

Standard Information

• Manufacturer: ECM Industries
• Brand: ILSCO

Technical Specifications

• Catalog Number: CT-500
• Conductor Size: 500 KCMIL
• Inner Diameter: 0.83 inches
• Outer Diameter: 1.062 inches
• Body Material: Electro-Tin Plated High Strength Seamless Copper
• Application: Grounding and bonding applications
• Voltage Rating: 600 VAC
• Temperature Rating: 90 degrees C
