ILSCO CT-250 Surecrimp Copper Compression Sleeve, Conductor Size 250, Tin Plated, UL, CSA

Product Description

The ILSCO CT-250 form a reliable connection for copper conductors sized 250 kcmil. This compression sleeve meets various electrical application standards and is essential for secure wire connections. It has a short barrel design with a chamfered end to aid in conductor insertion.

• Designed for copper conductors only
• Can be used for high voltage applications up to thirty-five kV
• Features low contact resistance and excellent conductivity

Product Highlights

This compression sleeve is ideal for grounding and bonding applications, ensuring strong connections in different environments.

Product Information

Standard Information

• Manufacturer: ECM Industries
• Brand: ILSCO

Technical Specifications

• Catalog Number: CT-250
• Conductor Size: 250 kcmil
• Inner Diameter: 0.59 inches
• Outer Diameter: 0.75 inches
• Material: Electro-tin plated high-strength seamless copper
• Approval: UL 486A/B, CSA
• Country of Origin: Mexico
• UPC: 783669122435
