Ilsco CSWD-3-14-58 Conduit Grounding Wedge Connector

Product Description

The ILSCO CSWD-3-14-58 is a conduit grounding wedge connector designed for reliable electrical grounding in conduit installations. This fitting creates a secure mechanical and electrical bond between the conduit system and a grounding conductor, ensuring continuity throughout the grounding path. It is installed by licensed electricians in commercial and residential conduit runs where a dependable ground connection is required at conduit termination or junction points. At 3.6 pounds, the CSWD-3-14-58 is a robust fitting suited for demanding field conditions.

This connector is used in conduit grounding applications where a wedge-style connection is specified. The wedge design provides a consistent clamping force without requiring solder or irreversible crimps, making it practical for both new construction and retrofit work. It is appropriate for use in panel feeders, junction boxes, and conduit grounding assemblies where code-compliant grounding continuity is required.

Key Features

• Wedge-style grounding connection for secure, consistent clamping force
• Suitable for conduit grounding continuity in commercial and residential installations
• No soldering required for installation
• Robust construction supporting demanding field environments
• UPC: 78366963217 for straightforward procurement and inventory tracking

Compatibility

Designed as an OEM-style replacement and direct-fit grounding connector for conduit grounding applications typical in commercial and residential electrical systems.

Installation Notes

Installation should be performed by a licensed electrician in accordance with NEC requirements for equipment grounding conductors. De-energize the circuit and verify absence of voltage before making any connections. Use appropriate hand tools to seat the wedge connector fully, ensuring solid mechanical contact between the conduit and the grounding conductor. Do not over-drive the wedge, as this may deform the connector body and compromise the ground path.

Technical Specifications

• Weight: 3.6 pounds
• UPC: 78366963217

Standard Information

• Brand: ILSCO
• Manufacturer Part Number: CSWD-3-14-58
