Ilsco CSWD-3/0-12-134 SureCrimp Copper Compression Lug 35 Volt 1/2in Pack 783669639490

Product Description

Ilsco CSWD-3/0-12-134 is a SureCrimp Copper Compression Lug designed for effective wire termination. This lug accommodates a conductor size of 3/0 AWG and features two mounting holes with a bolt size of one half inch. The hole spacing measures one and three quarter inches. Its standard barrel structure includes a sight window for visual inspection. The lug is tin plated to enhance conductivity and resistance to corrosion.

• Conductor size: 3/0 AWG
• Two mounting holes with one half inch bolt size
• UL and CSA compliant

Product Highlights

This copper compression lug is suitable for direct burial applications, making it ideal for various electrical installations. It supports a voltage rating of thirty-five kV and features a temperature rating of ninety degrees Celsius.

Product Information

Standard Information

• Brand: Ilsco
• Sub Brand: SureCrimp

Technical Specifications

• Overall Length: 4.189 inches
• Width: 0.885 inches
• Height: 0.649 inches
• Weight: 0.123 lb
• Material: Copper
• Voltage Rating: 35 Volt
• Barrel Length: 0.75 inches
• Stud Size: 1/2 inches
• Number of Holes: 2
• Color Coding: Orange
• Inside Diameter: 0.484 inches
• Outside Diameter: 0.609 inches
