Product Description
The ILSCO CSWD-2/0-38-1 is a copper compression lug designed for conductor sizes of two/zero AWG. It features two holes spaced one inch apart, accommodating a three-eighth inch bolt size. The product is suitable for various applications including grounding and bonding. It is made from seamless electro-tin plated copper, ensuring strong conductivity and durability.
- Suitable for high voltage applications up to thirty-five kilovolts when proper techniques are applied.
- Features a sight window for visual inspection of cable insertion.
- UL and CSA approved for reliable use.
Product Highlights
This compression lug provides low contact resistance and helps reduce inventory requirements due to its versatility. It is ideal for professional electricians and technicians in need of reliable connection products.
Product Information
Standard Information
-
Brand: ILSCO
-
Manufacturer: ECM Industries
Technical Specifications
-
Catalog Number: CSWD-2/0-38-1
-
Conductor Size: 2/0 AWG
-
Stud Size: 3/8 Inch
-
Barrel Length: 0.75 Inch
-
Pad Hole Spacing: 1 Inch
-
Material: Seamless Electro-Tin Plated Copper
-
Number of Pad Holes: 2
-
Approval: UL 453G, UL 467, UL 486A/B, CSA
