ILSCO CLWS-8-14 Surecrimp Copper Compression Lug 8 AWG 1/4 Inch Bolt Size

Product Description

The ILSCO CLWS-8-14 is a copper compression lug designed for use with wires of eight AWG size. This compression lug features one mounting hole with a stud size of one-quarter inch. The product is made from seamless copper tubing that enhances conductivity, ensuring reliable electrical connections.

• Manufactured from seamless copper for durability
• Color-coded for easy identification of the proper compression die
• UL listed and CSA certified for quality assurance

Product Highlights

This lug is suitable for both general and high voltage applications, granting versatility in electrical projects.

Product Information

Standard Information

• Brand: ILSCO
• Manufacturer: ECM Industries

Technical Specifications

• Catalog Number: CLWS-8-14
• Conductor Size: 8 AWG
• Barrel Length: 0.812 Inch
• Stud Size: 1/4 Inch
• Color: Red
• Material: Seamless Electro-Tin Plated Copper
• Temperature Rating: 90 Degrees Celsius
• Voltage Rating: 600 VAC
• Die Index: I-21
• Cross Reference Products: Ilsco CLNS-8-14, Panduit LCBX8-14-L
