ILSCO CLWS-4-14 Surecrimp Copper Compression Lug Conductor Size 4 1 Hole 1/4in Bolt Size

Product Description

ILSCO CLWS-4-14 is a copper compression lug designed for conductor size 4 with a one-hole connection. This compression lug features a long barrel and is ideal for various electrical applications. It supports a stud size of one-quarter inch and is UL listed and CSA certified.

• Manufactured from seamless copper tubing for enhanced conductivity.
• Chamfered entry allows easy insertion of conductors.
• Electro-tin plating reduces contact resistance.

Product Highlights

This lug offers application versatility and may be used in high voltage applications up to thirty-five kilovolts with the correct spacing and insulation techniques.

Product Information

Standard Information

• Catalog Number: CLWS-4-14
• Brand: ILSCO
• Manufacturer: ECM Industries
• UPC: 783669630312

Technical Specifications

• Conductor Size: 4 AWG
• Stud Size: 1/4 Inch
• Barrel Length: 1.125 Inch
• Material: Copper
• Approval: UL 453G, UL 467, UL 486A/B, CSA
• Color: Gray
• Overall Length: 2.039 Inch
• Die Index: I-29
